Beyerdynamic TG D57C Condenser Cardioid Drum Microphone BD707015 $ 229 $249.00
How to get it Learn More
Delivery Not Available
Order Special Order - Request Availability
Talk to a specialist

Chat to us or call 5444 8889

Seen a better price?

Find out more

Description

TG D57c

Whether with standing toms, snare drums or percussion instruments - with its patented clip-on mount and integrated pre-amplifier, the TG D57c condenser microphone is mounted and ready in a flash.

The expanded frequency range ensures faithful reproduction of all drum types and the 72 mm long flexible gooseneck allows it to be optimally positioned relative to the sound source. An elastic capsule suspension on the capsule housing protects against damage from drumstick strikes. The new electronics provide increased level accuracy and guarantee a very high maximum sound pressure level – even with phantom powering below 44 V.

  • Clip-on microphone for use at standing toms, snare drums or percussion instruments
  • Microphone clamp with integrated pre-amplifier
  • Expanded frequency range ensures faithful reproduction
  • Increased level accuracy and high maximum sound pressure level


Specifications

Transducer type . . . . . . . . . . . . . . . . Condenser (back electret)
Operating principle. . . . . . . . . . . . . . Pressure gradient
Polar pattern . . . . . . . . . . . . . . . . . . Cardioid
Frequency response
Close miking . . . . . . . . . . . . . . . . . . 20 -20,000 Hz
Distant miking (measured at 1 m) . . . 35 -20,000 Hz
Open circuit voltage . . . . . . . . . . . . . 5 mV/Pa (-46 dBV) ±2.5 dB
Nominal impedance . . . . . . . . . . . . . 200Ω
Load impedance . . . . . . . . . . . . . . . .≥1 kΩ
Max. SPLat 24 V and 48 V phantom power . . 140 dB
S/N ratio . . . . . . . . . . . . . . . . . . . . . . 59 dB [CCIR; Q-Peak]
70 dB [A; RMS]
Equivalent SPL . . . . . . . . . . . . . . . . . 35 dB [CCIR; Q-Peak]
24 dB [A; RMS]
Power supply . . . . . . . . . . . . . . . . . . Phantom power: 12 - 48 V
(recommended: 48 V)
Power consumption . . . . . . . . . . . . . 4.7 mA
Connection . . . . . . . . . . . . . . . . . . . 3-pin XLR, male
Dimensions
Clamp (W x H) . . . . . . . . . . . . . . . . . 85 x 118 mm
Gooseneck length . . . . . . . . . . . . . . 72 mm
Weight . . . . . . . . . . . . . . . . . . . . . . . approx. 145 g
