Rated Power Output 10 W (5 W+5 W) Nominal Input Level GUITAR/STEREO IN L, R: -10 dBu (1 M ohm) i-CUBE LINK/AUX IN: -20 dBu (15 k ohm) Nominal Output Level LINE OUT L/MONO, R: -10 dBu Speakers 10 cm (4 inches) x 2 Controls POWER switch AMP TYPE knob (ACOUSTIC SIM, JC CLEAN, US COMBO, BRIT COMBO, HI-GAIN STACK, METAL STACK, EXTREME, MIC, STEREO IN) MEMORY button GAIN knob VOLUME knob BASS knob MIDDLE knob TREBLE knob EFFECTS knob (CHORUS, FLANGER, PHASER, TREMOLO, HEAVY OCTAVE) DELAY/REVERB knob (DELAY, REVERB, SPRING) TAP button MIC VOL knob MASTER knob LOOPBACK switch (i-CUBE LINK/AUX IN) LOOPBACK switch (USB) Indicators POWER MEMORY TAP REC PLAY DUB Connectors GUITAR jack/STEREO IN L, R jacks: 1/4-inch phone type PHONES/REC OUT jack: Stereo Miniature phone type (Stereo, CTIA) i-CUBE LINK/AUX IN jack: Stereo Miniature phone type (Stereo, CTIA) LINE OUT L/MONO, R jacks: 1/4-inch phone type FOOT SW jack: 1/4-inch TRS phone type Bluetooth ADAPTOR connector: Dedicated connector USB port: USB B type DC IN jack Power Supply AC adaptor (DC 9 V) Alkaline battery (AA, LR6) x 8 Rechargeable Ni-MH battery (AA, HR6) x 8 Current Draw 360 mA Expected battery life under continuous use Alkaline battery: Approximately 8 hours Rechargeable Ni-MH battery: Approximately 10 hours (*1) *1 When using batteries having a capacity of 2,500 mAh. * These can vary depending on the specifications of the batteries, capacity of the batteries, and the conditions of use. Accessories Owner's Manual Leaflet USING THE UNIT SAFELY AC adaptor Power cord Mini cable (4-pole miniature phone type) Options (sold separately) Footswitch: FS-5U, FS-6, FS-7 Bluetooth® Audio MIDI Dual Adaptor (MODEL BT-DUAL) Wireless MIDI Expression Pedal: EV-1-WL Size and Weight Width 341 mm 13-7/16 inches Depth 162 mm 6-7/16 inches Height 215 mm 8-1/2 inches Weight (excluding AC adaptor) 3.3 kg 7 lbs 5 oz * 0 dBu = 0.775 Vrms
