dB Technologies DVA KS20 SUB 2x18" Active Bassreflex-Horn loaded Subwoofer DVA-KS20 $ 7712 $9,405.00
How to get it Learn More
Delivery Not Available
Order Special Order - Request Availability
Talk to a specialist

Chat to us or call 5444 8889

Seen a better price?

Find out more

Description

Featuring a double 18" woofer pairing in a bass reflex housing, the DVA KS20 is equipped with 2x Digipro G3 Power Amplifiers delivering 4000 W Peak. The system's internal design brings together the benefits of bass reflex and horn- loaded systems in a compact, sturdy housing covered with robust black laquer. The 56 Bit DSP manages limiters and delays for flawless system processing.
DVA KS20 is the perfect low-end complement for larger DVA K5 systems and can be used vertically in groundstacked configurations thanks to the DRK-20/10 pickpoints on top.

Specifications

Speaker Type Active Bassreflex-Horn loaded Subwoofer

Acoustical data
Frequency Response [- 10 dB] 41 Hz - 120 Hz

Max SPL 138 dB

Directivity Omnidirectional

LF 2x18 "

Voice Coil LF 4 "

Amplifier
Amp Technology Digipro® G3

Amp Class Class D

RMS Power 1800 W

Peak Power 3600 W

Cooling Convection

Power Supply 1800 W SMPS with auto range PSU

Processor
Controller DSP 56 Bit

AD/DA Converter 24 Bit /48 Hz

System Presets X-Over, Delay

Limiter Dual Active Multiband RMS, Peak, Thermal

Crossover Frequency LF-HF 90, 120 Hz (selectable)

Slope LF-HF 24 dB/Octave

Input
Input Selection 2x XLR Balanced

Output Selection 2x XLR Balanced

Power Socket 1x PowerCON in + 1x PowerCON Out

Controls 1 x Input Sensitivity Rotary Switch
  1 x Setup Rotary Encoder (delay up to 4.5 ms on-board)
  1 x Polarity Inversion Switch
  1 x X-over Frequency Switch (90 Hz, 120 Hz)
  1 x Output mode Switch (Link- X-Over)

Mechanics
Housing Plywood

Handles 3x Per Side

Rigging Points 2xPick Points on top to fix
  DRK10/20 rigging frames

Pole Mount 1 xM20 on top

Width 1100 mm (43.31 in)

Height 580 mm (22.83 in)

Depth 720 mm (28.53 in)

Weight 84 kg (185.19 lbs)
