dB Technologies DVA MS12 W AOR Active Bass-Reflex Flyable Subwoofer, 1x12" Woofer, 700W White DVA-MS12-W $ 3013 $3,674.00
How to get it Learn More
Delivery Not Available
Order Special Order - Request Availability
Talk to a specialist

Chat to us or call 5444 8889

Seen a better price?

Find out more

Description

AOR Active Bass-Reflex Flyable Subwoofer, 1x12" Woofer, 700 W/RMS, 45-140 Hz, 131dB SPL, SMPS with auto-range, Integrated flying hardware, Dimensions: 460x430x385 mm, Weight: 26.5 kg WHITE

DVA MS12 is the flyable subwoofer which comes with the DVA Mini series.

Especially designed to fit perfectly with an M2M and M2S array, the MS12 is equipped with a single 12″ woofer in a bass reflex enclosure, acting as a perfect low-end extension module for DVA Mini systems.

* Available in black or white.

Specifications

Technical Data

  • Speaker Type: Active bass reflex flyable subwoofer

Acoustical Data

  • Frequency Response [-6dB]: 45 – 140 Hz
  • Frequency Response [-10dB]: 40 – 165 Hz
  • Max SPL: 131 dB
  • LF: 12″
  • Voice Coil LF: 3″
  • Directivity: Omnidirectional

Amplifier

  • Amp Technology: Digipro® G3
  • Amp Class: Class D
  • Power Supply: 700W SMPS with PSU Auto-range (110V~ and 220V~)
  • LF Amp: 700 W RMS (1400 W Peak)
  • Cooling: Convection

Processor

  • Controller: DSP 56 bit
  • AD/DA Converter: 24 bit/48 kHz
  • Controls: X-Over frequency selection, Phase selection (0° or 180°), Outputs mode selection (Link/X-over), Mini-USB type “B” port (service data)
  • Limiter: Dual active, RMS/Peak, Thermal
  • Crossover Frequency LF-HF: 90 – 120 Hz
  • LF X-over out slope: 24 dB/Octave

Mechanics

  • Housing: Multiplex birch plywood – Polyurea painting
  • Handles: 1x left side, 1x right side
  • Feet: 4x Dual Position Reversible Feet (flying/stacking mode)
  • Fittings: M20 screw for pole mount on top side, integrated hardware with fast lock mechanics
  • Width: 460 mm (18.1 in)
  • Height: 430 mm (16.9 in)
  • Depth: 385 mm (15.2 in)
  • Weight: 26.5 kg (58.4 lbs)
