Technical Data
- Speaker Type: Passive Speaker
Acoustical data
- Frequency Response [-6dB]: 140 – 18000 Hz
- Max Power: 100 W Peak
- MF – HF: 4×4″, v.c. 1″
- Type MF – HF: Neodymium
- Directivity: 97×60°
Input
- Audio Connector: 4-Pole Speakon
Mechanics
- Housing (Tops): Plywood with full metal grille
- Pole Mount: 36 mm (M20 Thread)
- Width (Top): 110 mm (4.33 in)
- Height (Top): 460 mm (18.11in)
- Depth (Top): 160 mm (6.30 in)
- Weight (Top): 3.3 Kg – 7.27 lbs.
Note: The data are not binding; dBTechnologies reserves the right to modify the data at any time and without previous notice.
