Technical Data
- Speaker Type: Passive Subwoofer
Acoustical Data
- RMS Power: 250 W
- Peak Power: 1000 W
- Frequency Response [-6 dB]: 40 Hz – custom LPF
- Impedance: 8 Ohm
- Sensitivity 1W@m: 97.5 dB
- Max SPL: 127.5 dB
- LF: 1x 12″, 2.5″ v.c.
Input
- Connections: Speakon or Phoenix version available
Mechanics
- Housing: Plywood, water-painted coating
- Rigging points: 16x M8 pickup point
- Width: 624 mm (24.6 in)
- Height: 335 mm (13.2 in)
- Depth: 400 mm (15.7 in)
- Weight: 15 kg (33 lbs)
Note: Data is not binding; dBTechnologies reserves the right to modify the data at any time and without notice.
