Technical Data
- Speaker Type: Passive 2-way Speaker
Acoustical Data
- RMS Power: 250 W
- Peak Power: 1000 W
- Frequency Response [-6 dB]: 80 hz – 20,000 Hz
- Impedance: 8 Ohm
- Sensitivity 1W@m: 94 dB
- Max SPL: 124 dB
- HF: 1x 1″, 1.7″ v.c.
- LF: 2x 6.5″, 1.7″ v.c.
- IS26T Dispersion: 60×90° [rotatable horn]
- IS26T100 Dispersion: 15×100° [H x V]
- X-Over Frequency: 1200 Hz (internal X-Over)
Input
- Connections: Speakon or Phoenix version available
Mechanics
- Housing: Plywood, water-painted coating
- Rigging points: 2x M10 threaded nut (top and bottom)
- Width: 210 mm (8.3 in)
- Height: 650 mm (25.6 in)
- Depth: 270 mm (10.6 in)
- Weight: 15.5 kg (34.17 lbs)
Note: Data is not binding; dBTechnologies reserves the right to modify the data at any time and without notice.
