Technical Data
- Speaker Type: Passive Fullrange Speaker
Acoustical Data
- RMS Power: 40 W
- Peak Power: 160 W
- Frequency Response [-6 dB]: 110 hz – 20,000 Hz
- Impedance: 8 Ohm
- Sensitivity 1W@m: 89 dB
- Max SPL: 111 dB
- LF: 1x 4″, 1 ” v.c. Fullrange woofer
- Dispersion: 110×110°
Input
- Connections: Speakon or Phoenix version available
Mechanics
- Housing: Plywood, water-painted coating
- Rigging points: 2x M6 threaded nut
- Accessories: Bracket included
- Width: 130 mm (5.1 in)
- Height: 130 mm (5.1 in)
- Depth: 150 mm (5.9 in)
- Weight: 2 kg (4.4 lbs)
Note: Data is not binding; dBTechnologies reserves the right to modify the data at any time and without notice.
