Technical Data
- Speaker Type: Passive 2-way Coaxial Speaker
Acoustical Data
- RMS Power: 100 W
- Peak Power: 400 W
- Frequency Response [-6 dB]: 85 hz – 20,000 Hz
- Impedance: 8 Ohm
- Sensitivity 1W@m: 93 dB
- Max SPL: 119 dB
- HF: 1x 0.75″, 1″ v.c. Neodymium
- LF: 1x 6.5″, 1.5″ v.c. Coaxial woofer
- Dispersion: 100×100°
- X-Over Frequency: 2100 Hz (internal X-Over)
Input
- Connections: Speakon or Phoenix version available
Mechanics
- Housing: Plywood, water-painted coating
- Rigging points: 2x M6 threaded nut
- Accessories: Bracket included
- Width: 195 mm (7.7 in)
- Height: 195 mm (7.7 in)
- Depth: 210 mm (8.3 in)
- Weight: 4.8 kg (10.6 lbs)
Note: Data is not binding; dBTechnologies reserves the right to modify the data at any time and without notice.
