dB Technologies LVX P15W 2-way Passive Speaker, 800W peak power at 8 ohms, 1 x 15" woofer White LVX-P15W $ 913 $1,113.00
How to get it Learn More
Delivery Not Available
Order Special Order - Request Availability
Talk to a specialist

Chat to us or call 5444 8889

Seen a better price?

Find out more

Description

2-way Passive Speaker, 800W peak power at 8 ohms, 1 x 15" woofer with 2.5" VC, 1" driver with rotatable 90°x60° horn, 129dB maximum SPL, 58Hz - 21kHz. 40º monitor angle, 12 x M8 threaded inserts. Dimensions 420x680x430mm, 19.7kg,

White

  • 2-way passive speaker
  • Clean design
  • Available in black or white
  • M8-thread rigging points
  • Rotatable horn for vertical or horizontal use
  • Wooden lightweight enclosure

Born as an evolution of wooden LVX active series, the new LVX P family moves into the installation world with a passive selection of cabinets where a clean, essential design merges with a very detailed and coherent audio performance.

LVX P cabinets are equipped with premium components and are designed to render speech, live or background music in medium to large venues delivering a clear, detailed audio performance.

Full range LVX P15 provides a 90°x60° dispersion pattern and is equipped with a rotatable horn to guarantee the same HF coverage even in case of horizontal install.

The solid plywood enclosures features a clean, install-friendly design featuring 12 M8-thread rigging points to ease installation with dedicated horizontal (WB-LP15H or vertical brackets (VB-LP1215V).

The cabinet features 1 integrated handle per side and a 36 mm pole mount plate.

All enclosures and accessories of LVX P series are available in black or white version.

Specifications

Technical Data

  • Speaker Type: 2-Way Passive Speaker

Acoustical Data

  • Peak Power: 800 W
  • Impedance: 8 Ohms
  • Frequency Response [- 10 dB]: 58 – 21.000 Hz
  • Max SPL: 129 dB
  • HF: 1 , 1.35″ v.c.
  • Directivity: 90×60 °
  • Horn: Rotatable
  • LF: 15, 2.5″ v.c.

Input

  • Signal Input: 1x Speakon (Pin 1+=+) (Pin 1-=-)
  • Signal Output: 1x Speakon (Pin 1+=+) (Pin 1-=-)

Mechanics

  • Housing: Plywood
  • Pole Mount: 36 mm
  • Angle Up: Monitor use 40°
  • Rigging Points: 12 x M8
  • Handles: 2 (1 per side)
  • Width: 420 mm
  • Height: 680 mm
  • Depth: 430 mm
  • Weight: 19.7 kg

Note: Data is not binding; dBTechnologies reserves the right to modify the data at any time and without previous notice.
