Focusrite Scarlett 18i16 4th Gen USB Audio Interface MOSC0036CNAUKR $ 719 $799.99

How to get it Learn More

Delivery Calculate Shipping

Store Click & Collect - Available In Stock

Online In Stock

Talk to a specialist

Chat to us or call 5444 8889

Seen a better price?

Find out more

Or Rent From

$6.93 per weekReturn any time after minimum rental agreement

Apply Now Learn More Apply to Purchase Info

Description

Scarlett 18i16 is the complete compact studio hub for all your instruments and outboard gear. Perfect for producers, 18i16 is equipped with enough I/O to connect all your studio gear. Four of our most detailed ultra-low-noise mic preamps. Hi-Z, line, and MIDI connections for your guitars, keys, synths, grooveboxes, and controllers. With 18i16 your headphones, monitors, and line outs each get their own mix, so you can match the studio setup to the session. Expand your channel count using the S/PDIF or ADAT connections.

Air mode, with Presence and Harmonic Drive, gives you that big console sound wherever you record. Auto Gain and Clip Safe make sure you'll never need to worry about your levels. The Hitmaker Expansion software bundle has all the tools you need to record, produce, and release your tracks. And the Focusrite Control 2 desktop and mobile apps enable you to remotely control your Scarlett anywhere in the studio. 18i16 can be powered directly from a computer's USB-C port (3A), so no extra power supply is needed.

Specifications

    Number of Microphone Preamps4
    Phantom PowerYes (Independent)
    Instrument Inputs2
    Line Inputs8
    Air ModeYes
    Auto GainYes
    Clip SafeYes
    Line Outputs4
    Headphone Outputs2
    ADAT Inputs1
    ADAT Outputs1
    SPDIF Inputs1
    SPDIF Outputs1
    SPDIF Outputs1
    MIDI Inputs1
    MIDI Outputs1
    LoopbackYes
    ConnectivityUSB Type-C
    ProtocolUSB 2.0
    Form FactorDesktop
    Simultaneous I/O20 x 18 (including Loopback)
    A/D Resolution24-bit/192 kHz
    Bus Powered Yes (3A)

Dimensions

    Height60.5mm
    Width240mm
    Depth169.4mm
    Weight1.494kg

Supported sample rates

44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz

Microphone inputs

    Frequency Response20-20kHz ± 0.06dB
    Dynamic Range116dB (A-Weighted)
    THD+N-100dB @ 8dB gain
    Noise EIN-127dBu (A-Weighted)
    Maximum Input Level16dBu
    Gain Range69dB
    Impedance3kΩ

Variable Line inputs

    Frequency Response20-20kHz ± 0.05dB
    Dynamic Range115.5dB (A-Weighted)
    THD+N-100dB @ 8dB gain
    Maximum Input Level22dBu
    Gain Range69dB
    Impedance24kΩ

Fixed Line inputs

    Frequency Response20-20kHz ± 0.02dB
    Dynamic Range115.5dB (A-Weighted)
    THD+N-106dB
    Maximum Input Level22dBu
    Impedance48kΩ

Instrument inputs

    Frequency Response20-20kHz ± 0.05dB
    Dynamic Range113dB (A-Weighted)
    THD+N-80dB @ 8dB gain
    Maximum Input Level12dBu
    Gain Range62dB
    Impedance1MΩ

Line outputs (Balanced)

    Frequency Response20-20kHz ± 0.02dB
    Dynamic Range122dB (A-Weighted)
    THD+N-112dB
    Maximum Output Level16dBu
    Impedance200Ω

Headphone outputs

    Frequency Response20-20kHz ± 0.1dB @ 33Ω / 300Ω
    Dynamic Range112dB @ 33Ω
    116dB @ 300Ω
    THD+N-100dB @ 33Ω (Minimum)
    -110dB @ 300Ω (Minimum)
    Maximum Output Level5dBu into 33Ω
    11dBu into 300Ω
    Maximum Output Power57mW into 33Ω
    27mW into 300Ω
    Impedance11Ω

Analogue to Digital Converter

THD+N-110dB
Dynamic Range120dB

Digital to Analogue Converter

THD+N-115dB
Dynamic Range130dB (A-Weighted)

Power

USB3A
External (Optional)15W

What's in the box

    Scarlett 18i16 audio interface
    1.5m USB-C to USB-C cable
    USB-C to USB-A adaptor
    External power supply

Visit manufacturers website for more information
