MIDAS Xl48 Microphone Preamplifier/Ad Converter 453008 $ 1799 $1,799.00
How to get it Learn More
Delivery Not Available
Order Special Order - Request Availability
Talk to a specialist

Chat to us or call 5444 8889

Seen a better price?

Find out more

Description

In response to the many customer requests received over the years, theÊMIDASÊXL48 DIG-LOG Microphone Preamplifier is a combination of the best of both analogue and digital worlds. XL48 features eight classic XL4 series microphone preamplifiers in a 1U 19" rackmount enclosure with the acclaimed low latency 24 bit 96 kHz ADC converters with overload protection from theÊMIDAS XL8ÊLive Performance System, and a precision reference clock oscillator with 1 part-per- million (ppm) stability. Additional features include swept high and low pass filters, 8 segment LED input meters, and individual phantom power, polarity invert, and -20 dB pad switches per channel. XL48 features both analogue outputs and digital outputs in ADAT optical and AES3 formats and all outputs can be used simultaneously, allowing the XL48 to be used as a multifunction analogue and/or digital microphone splitter. Multiple internal sample rates are supported, with the option to sync to external word clock. XL48 is ideal for use in portable recording rigs, analogue and digital splits between consoles, or indeed augmenting the performance of other mixing consoles with itsÊMIDASÊXL4 microphone preamplifiers, XL8 analogue-to-digital conversion and precision reference-grade 1 ppm internal clock oscillator.,Award-winning Midas XL4 analogue microphone preamplifiers with switchable +48 V phantom power,Low latency 24 bit 96 kHz ADC converters with overload protection,2 ADAT* optical output ports with 75 ohm BNC connector for external word clock,8 inputs with Neutrik* XLR connectors and parallel 25 way D-type connector

Specifications

Maximum Input Level

  • Mic\Line: +11 dBu
  • Mic\Line + Pad: +31 dBu



CMR at 1KHz (Typical)

  • Mic (gain + 40 dB): > 80dB
  • Mic + Pad (gain + 40 dB): > 70 dB



Noise

  • Mic EIN at 60 dB gain: -128 dBu
  • Mic EIN at 40 dB gain: -125 dBu
  • Output noise at minimum gain: -95 dBu



Frequency Response

  • 20 Hz – 20 kHz: +0 dB to -1 dB



Distortion at 1 kHz

  • Input to output (0 dB): 0.03%



Crosstalk at 1 kHz

  • Channel to Channel: < -90 dB



Maximum Output Level

  • Line Outputs (into 600R): +21 dBu



Digital Output

  • Sampling Frequency: 96, 88.2, 48 or 44.1 kHz
  • Bit Rate: 24 Bit Only
  • Dynamic Range (20 Hz-20 kHz): > 110 dB



Power Requirements

  • Voltage: 100 V a.c. to 240 V a.c. ±10%
  • Frequency: 50 Hz to 60 Hz
  • Consumption: < 25 W



Weight and Dimensions

  • Width 483.0 mm (19.0”) x Depth 325 mm (12.8”)
  • Weight: 5.5 Kg
  • Shipping: 6.5Kg
