Main components

• 10-inch glass-composite low-frequency transducer
• Front-firing, bass-reflex acoustic port

​Controls and filters

• Input gain control (-30 dB to +6 dB, continuously variable)
• Continuously variable lowpass filter (50 Hz to 130 Hz)
• Built-in crossover
• Switchable highpass filter removes frequency content below 80 Hz from the full-range signal sent from the T10 outputs to the main monitors
• Momentary footswitch (included) bypasses the subwoofer, highpass filter, and Sub Out
• Polarity invert and ground-lift switch

Power and safety

• 250 watt, Class AB amplification
• Internal damping and heat sink
• Integrated, gravity-calibrated rubber feet for stable placement

Inputs and outputs

• Left and right, balanced XLR and ¼” TRS and unbalanced RCA main inputs
• Left and right balanced XLR and ¼” TRS outputs
• XLR subwoofer output for connecting a second T10

Customize your system until it’s just right.

The T10 provides more user controls than any other subwoofer in its class, enabling seamless integration into your listening environment.

The Temblor T10’s extensive user controls include input gain (-30 dB to +6 dB, continuously variable) and a continuously variable lowpass filter (50 Hz to 130 Hz) that let you create a seamless crossover transition between your full-range studio monitors and subwoofer for a more accurate listening environment.

A switchable highpass filter removes frequency content below 80 Hz from the full-range signal sent from the T10 outputs to the main monitors, avoiding destructive cancellation and reinforcement in the T10’s upper range.

The result is a subwoofer that can be adjusted to perfectly complement not only our Sceptre™ CoActual™ and Eris™ active studio monitors but virtually any studio monitor.

The T10 also features a momentary footswitch (included) that bypasses the subwoofer, highpass filter, and Sub Out. This allows your audio source signal to pass directly through the Temblor T10 to the full-range studio monitors, making comparing your mix with or without sub frequencies quick and easy. This helps to ensure your mix will sound good on a wide variety of systems.

Of course, we didn’t forget the “small things” that can make a big difference: polarity invert and a ground-lift switch.



























Versatile I/O works with any setup.

No other subwoofer anywhere close to the Temblor T10’s price range offers a comparable selection of inputs and outputs.
